Ortur Laser Master 2 ProS2 40*40cm Table Lase Engraver Cutter For Woodworking Powerful Wood Metal CNC Engraving Cutting Machine
Why choose DIY KIT 10W?
DIY KIT 10W is an upgraded motherboard based on OLM2PROS2 LU2-10A, with stronger internal driving force and new mobile phone control functions. The light spot is 0.05*0.01, the same engraving accuracy and cutting ability!
Welcome to Ortur Outlet Store!
Power Adapter Output:24V / 3A
Operating Temp:-20℃-50℃
5 Satety Protection:
1. Active Position Protection: When the machine is displaced or tilted, it would automatically stop the laser to prevent damage caused by the laser shot out of the target.
2. Laser Beam Safety Guard: When the machine or computer from crashing during the engraving process, it would automatically stop the laser.
3. Exposure Duration Detection and Limitation: When the motors have no movement for a while, it would automatically stop the laser.
4. Flame detector + buzzer alarm: When the detector detect the flame, the buzzer alarm would sound and light alarm.
5. Emergency Stop Button: Any emergency, you could press the emergency stop button.
Ortur Laser 1.8 Series Firmware has been optimized for faster speed engraving. Taking advantage of the faster ESP32 McU.
1. The main frequency is as high as 240MHZ.
2. The working efficiency is high, and the machine moves fast.
3. With current and voltage detection functions, better protection of the machine.
4. Active power-off function, which can actively disconnect the power supply in the case of abnormal power supply.
5. Support LU3 series digital Laser module, it could adjust the laser heat dissipation time after the engraving is completed according to the use of the digital laser module.
6. The use of efficient real-time operating system Freertos system is more stable and more efficient.
TIPS
LU2-10A:More Powerful Engraving with True 10W Output Power LU2-10A is newly upgraded with a 10W laser module, which makes the cutting speed up to 15,000 mm/min. The compressed point is 0.05mm x 0.1mm.The optical power reaches to 10W. It can cut 30mm acrylic and 20mm wood. At the same time, the laser module of the engraving machine has a built-in air-assist interface, which is designed for cutting.
